We supply BT40 Pull studs,CAT,DIN 69872 A/B ,ISO 7388 and other standard pull stud .Good Quality and competitive price bring us much customers from Europe and USA . Pull stud are mostly used with following products :

Tool Holder Shanks: BT Tool Holders, DIN69871 SK Tool Holders, NT Tooling, CAT30 CAT40 CAT50
Tool Holders, HSK Tool Holders, DIN 69880 VDI Tool Holders, Morse Taper, Straight Shank Tool Holders, etc.

Tool Holders: Collet Chucks, Milling Chucks, Face Mill Holders, Weldon End Mill Holders, Morse Taper
Adapters,Drill Chucks, Tapping Chucks, Shrink Chucks, Thread End Mill Tool Holders, Screw in Milling
Cutter Holders, etc.

Collet: ER Collets, ERC Collets, ERG Collets,Milling Chuck set ,Straight Collets, OZ Collets, etc.

Features of pull stud bt40 :

Descriptions of pull stud bt40 :

Cutoutil Hardware Tools Co.,LtD is a professional company specialized in cutting tools, Diamond tools, Machine Accessories and measuring tools.

The scope of main products included turning tools milling tools, Carbide End Mills, Carbide Ball End Mills and carbide burrs, Carbide Drills & milling cutter, carbide inserts and ER collets, chucks, pull stud bt40.

Related products :

Shipping :

-The items will be shipped out within 3-7days after received your payment.

-We usually ship items via DHL, TNT, Fedex, UPS, Airmail, ePacket, EMS, china Post. Air Mail.

Pull Stud (BT40)

Overview

The Pull Stud (BT40) is a critical component used in CNC machining centers, specifically for securing tool holders in the spindle. It ensures that the tool holder remains firmly in place during machining operations, providing stability and accuracy.

Technical Specifications

Type: BT40

Material: Typically made from high-strength steel, such as 20CrMnTi

Surface Hardness: HRC 56-58

Diameter (D): 16 mm

Diameter (D1): 17 mm

Diameter (D2): 19 mm

Thread Size (M): M24

Length (L): 60 mm

Length (L1): 42 mm

Length (L2): 18 mm

Head Diameter (H): 25 mm

Head Length (H1): 10 mm

Usage

Spindle Connection: The Pull Stud is inserted into the spindle and engages with the tool holder's retention knob, ensuring a secure fit.

Angle Compatibility: Common angles for the Pull Stud include 30°, 45°, and 90°, depending on the specific application and tool holder design.

Surface Treatment: Surface treatments such as carburizing and hardening (HRC 52-58) enhance wear resistance and durability.

Benefits

High Strength: Made from high-strength steel, ensuring reliability and longevity.

Precision Fit: Precise dimensions ensure a perfect fit with the spindle and tool holder.

Versatility: Compatible with various types of tool holders and machining operations.

Ease of Maintenance: Easy to install and replace, reducing downtime.
