Insert Wnmg
Insert Wnmg
80° Rhombic insert
Double sided
Negative rake
Good edge strength
High wear resistance
High toughness
Long service life
High processing stability
Coating: PVD or CVD
Available in a range of radius for finishing, general purpose and rough turning
Description
Insert Wnmg
Specifications of insert-wnmg:
WNMG is not actually an acronym & yes it is the type of insert. Each letter of an insert designation is a value, you have to look at a chart to decipher the code. Insert designations are an industry standard and the sizes (numbers after the insert code) are sized in ANSI (imperial) or ISO (metric).
Double-Sided Trigon Inserts for Machining a Wide Range of Materials at Medium Cutting Conditions

| insert shape | Type | Size (mm) | ||||
| L | ΦI.C | S | Φd | r | ||
| DF Fine finishing | CNMG090304-DF | 9.7 | 9.525 | 3.18 | 3.81 | 0.4 |
| CNMG090308-DF | 9.7 | 9.525 | 3.18 | 3.81 | 0.8 | |
| CNMG120404-DF | 12.9 | 12.7 | 4.76 | 5.16 | 0.4 | |
| CNMG120408-DF | 12.9 | 12.7 | 4.76 | 5.16 | 0.8 | |
| CNMG120412-DF | 12.9 | 12.7 | 4.76 | 5.16 | 1.2 |

WNMG inserts is matching with WWLNR series turning tools :
MODEL # | D | DIME F | NSlOh L | qs MIN BORE | .INSERT SIZE | ITEM NO. RIGHT LEFT | SHIM | SHIM PIN | CLAMP CLAMP SCREW WRENCH | ||
