Er Collet Holders
Er Collet Holders
1.Product Name :er collet holders
2. Accurancy :0.005
3.Material :20crmoti
4.Colour :Silver
Description
Er Collet Holders
SPECIFICATIONS of er collet holders:
BT30, BT40, BT45, BT50, BT60 ,SK30,SK40,SK50 er collet holders
Tool holder series, CNC tool holder, CNC tool holder, collet chuck, high speed tool-holder, machine tool holder,
chuck, Powerful toolholder, CNC toolholder, ER toolholderis divided into BT toolholder, NT toolholder, MT toolholder, etc.,
The main models are:
BT toolholder: BT30, BT40, BT50 and so on
NT Tool Holder: NT30, NT40, NT50 and so on
MT toolholder: MT1, MT2, MT3, MT4, MT5, MT6 and so on
Woodworking toolholder: ISO20, ISO25, ISO30, HSK40, HSK50, HSK63
American Standard A. N. S. I. B5.50 CAT Series
R8 handle: R8-ER type, R8-OZ series and so on
| Product | Good price SK40 ER32 ER Collet Chuck for lathe |
| Material | High quality steel, good surface treatment, black-finished and precisely grinded |
| Applications | For clamping tools with straight shank in collets of DIN6499 |
| Taper tolerance | <AT3 |
| Hardness | HRC56-58 |
| Carbon depthe | 0.8mm±0.2mm |
| Max. runout | <0.005mm |
| Surface roughness | Ra<0005mm |
| Shank body standard | DIN7981 |
| Model | L | L1 | d1 | d2 |
| SK30-ER16-45L | 113.4 | 45 | 28 | 16 |
| SK30-ER20-45L | 113.4 | 45 | 34 | 20 |
| SK30-ER25-55L | 123.4 | 55 | 42 | 25 |
| SK30-ER32-60L | 128.4 | 60 | 50 | 32 |
| SK30-ER40-70L | 138.4 | 70 | 63 | 40 |
| SK40-ER16-45L | 138.4 | 45 | 28 | 16 |
| SK40-ER20-45L | 138.4 | 45 | 34 | 20 |
| SK40-ER25-55L | 148.4 | 55 | 42 | 25 |
| SK40-ER32-60L | 153.4 | 60 | 50 | 32 |
| SK40-ER40-70L | 163.4 | 70 | 63 | 40 |
| SK40-ER50-80L | 173.4 | 80 | 78 | 50 |
| SK50-ER11-100L | 226.8 | 100 | 19 | 11 |
| SK50-ER16-100L | 226.8 | 100 | 28 | 16 |
| SK50-ER20-100L | 226.8 | 100 | 34 | 20 |
| SK50-ER25-100L | 226.8 | 100 | 42 | 25 |
| SK50-ER32-75L | 201.8 | 75 | 50 | 32 |
| SK50-ER32-100L | 226.8 | 100 | 50 | 32 |
| SK50-ER40-80L | 206.8 | 80 | 63 | 40 |
| SK50-ER40-100L | 226.8 | 100 | 63 | 40 |
| SK50-ER50-80L | 206.8 | 80 | 78 | 50 |
| SK50-ER50-100L | 226.8 | 100 | 78 | 50 |
| Type | Model | A | L | NUT | |
| ER type | A | ER11A | 17.2 | 129 | ER11-A |
| ER11A | 25.2 | 140 | ER16-A | ||
| ER11A | 30.3 | 156 | ER20-A | ||
| M | ER8M | 7.5 | 77 | ER8-M | |
| ER11M | 11 | 96 | ER11-M | ||
| ER16M | 15 | 110 | ER16-M | ||
| ER20M | 19.5 | 132 | ER20-M | ||
| UM | ER25UM | 37 | 215 | ER25-UM | |
| ER32UM | 46.5 | 255 | ER32-UM | ||
| ER40UM | 58 | 295 | ER40-UM |
