Tapered End Mill
Tapered End Mill
1.Product Name :tapered end mill
2.Accurancy :0.005
3.Material :20crmoti
4.Colour :Silver or black
Description
Tapered End Mill
Specifications of tapered end mill :
Tips: The following specifications are standard Size, with a large amount of stock. At the same time, we support customized production, the diameter is 0.2mm to 25mm, the Total length is 50mm to 200mm, include inch size end mill , the number of Flute is 4F, 5F, 6F, 8F and the logo could becustomized.
﹏﹏﹏﹏﹏Features ﹏﹏﹏﹏﹏
(1) Micrograin solid carbide end mill
(2) Excellent combination of upper and lower blades, SHARP cutting edge;
(3) High precision grinded and polished, high abrasion resistance and temperature resistance, good rigidity, not easy to break;
(4) No burrs for Up and down spiral machining;
(5) High performance, improve the work efficiency, reduce cost;
| Specification | Flute Diameter(d) | Flute Length (l) | Shank Diameter(D) | Overall Length(L) | Flutrs(Z) |
| D1*3*D4*50*4T | 1 | 3 | 4/6 | 50 | 4 |
| D1.5*4*D4*50*4T | 1.5 | 4 | 4/6 | 50 | 4 |
| D2*6*D4*50*4T | 2 | 6 | 4/6 | 50 | 4 |
| D2.5*7*D4*50*4T | 2.5 | 7 | 4/6 | 50 | 4 |
| D3*8*D3*50*4T | 3 | 8 | 3/4/6 | 50 | 4 |
| D3.5*9*D4*50*4T | 3.5 | 9 | 4/6 | 50 | 4 |
| D4*12*50*4T | 4 | 12 | 4/6 | 50 | 4 |
| D4*15*75*4T | 4 | 15 | 3/4 | 75 | 4 |
| D4*20*100*4T | 4 | 20 | 4 | 100 | 4 |
| D5*15*D5*50*4T | 5 | 15 | 5/6 | 50 | 4 |
| D5*20*75*4T | 5 | 20 | 5/6 | 75 | 4 |
| D5*25*D5*100*4T | 5 | 25 | 5/6 | 100 | 4 |
| D6*18*50*4T | 6 | 18 | 6 | 50 | 4 |
| D6*20*75*4T | 6 | 20 | 6 | 75 | 4 |
| D6*25*100*4T | 6 | 25 | 6 | 100 | 4 |
| D6*30*120*4T | 6 | 30 | 6 | 120 | 4 |
| D6*30*150*4T | 6 | 30 | 6 | 150 | 4 |
| D7*20*D8*60*4T | 7 | 20 | 8 | 60 | 4 |
| D8*24*60*4T | 8 | 24 | 8 | 75 | 4 |
| D8*25*75*4T | 8 | 25 | 8 | 75 | 4 |
| D8*30*100*4T | 8 | 30 | 8 | 100 | 4 |
| D8*45*120*4T | 8 | 45 | 8 | 120 | 4 |
| D8*45*150*4T | 8 | 45 | 8 | 150 | 4 |
Related Products of tapered end mill：
Company Introduction:
We are focus on producing cemented carbide burrs ,carbide inserts ,carbide drills and carbide end mills ,ER collets ,cnc er chuck collet over 10years . We also supply cnc toolholder as well as famous brand products like korloy ,mitsubishi ,sumitomo ,seco ,sandvik .
| JS453200E3R050.0Z3-HEMI | JS453200E3R200.3Z3-HEMI |
| JS453200E3R050.3Z3-HEMI | JS453200E3R300.0Z3-HEMI |
| JS453200E3R100.0Z3-HEMI | JS453200E3R300.3Z3-HEMI |
| JS453200E3R100.3Z3-HEMI | JS506030N2CZ3.0-SIRA |
| JS453200E3R200.0Z3-HEMI | JS506040N2CZ3.0-SIRA |
Workshop:
We use ANCA and Walter machines to produce all carbide tools .
Quality Control and Warehouse :
Package and Shipping :
Hot Tags: tapered end mill, China, manufacturers, suppliers, factory, cheap, low price, made in China, corner rounding cutter, corner radius milling cutters, indexable ball nose end mill, solid carbide end mill, aluminum cutting end mills, carbide ball nose end mill
